Base Cabinet Construction List
Overlay Dimensions
The drawings shown below illustrate the relationship between the cabinet face frame and Partial Overlay (POL) and Full
Overlay (FOL) doors. They show the amount of the cabinet face frame that is visible when Partial Overlay doors or Full
Overlay doors are selected.
Base Cabinet Construction
The drawing below illustrates and identifies the parts of a standard base cabinet.
Base Cabinet dimensions
The drawing below illustrates and identifies the parts of a standard base cabinet.
Base Panel
The bottom panel supporting the cabinet structure
Side Panel
Vertical panel on the side of the cabinet
Back Panel
Panel at the back of the cabinet for stability
Face Frame
Front wooden frame for cabinet support and mounting doors
Toe Kick
Recessed area at the base for foot space
